Edgeline Personal Identity Verification Module

Personal Identity Verification Module

features

4-in-1 reader attachment:fingerprints, magnetic stripes, contact and contactless smart cards
Equips mobile computer user to securely identify field personnel
Ideal for security applications in military, emergency management and law enforcement
Supports multi-step authentication
Fast and easy to install

product specifications

ROHS & WEEE compliant

os versions supported
Microsoft®WindowsMobile®5.0
Microsoft®WindowsMobile®6.1

physical
Dimensions(mm): 48Hx84.5Wx134D (1.89”Hx3.33”Wx5.26”D)
Weight: 156g(5.5oz)

environmental
Operating Temp: -10°–50° C (14°–122° F)
Drop Spec: 4 ft (1.22m), 26x all faces, sides and corners
Environmental Protection: IP54 compliant

accessories
CN3 Single Dock and CN3 Multi-Dock
Enables charging and data synchronization
(via USB ActiveSync & Ethernet)
with the mobile computer while the PIV module is connected

DATA INPUT TECHNOLOGIES:

Biometric Fingerprint Reader
FIPS 201 & NIST 800-76 standards compliant
FBI PIV-IQF compliant
0.55 x 0.87 in (14 x22 mm) optical sensor
500 DPI, 8 bits per pixel

Magnetic Stripe Card Reader
ISO 7810 & 7811 standards compliant
Formats supported: ISO 7811 and AAMVA
Card Thickness Supported: 0.76mm ± 0.08mm

Contact Smart Card Reader
ISO 7816 & 7810, GSC-IS & EMV Level 1 standards compliant
Formats supported: Asynchronous (T=0 & T=1 protocols) and Synchronous

RFID Contactless Smart Card Reader
ISO 14443, FIPS 201 and NIST 800-73 standards compliant
Provides a read-only interface with a maximum read range of 10cm

Industrial Uses:

law enforcement

Drivers license identification methods vary from state to state, from use of magnetic stripes to bar codes to smart cards. Fingerprinting is also becoming more commonly used when positive identification is needed. The PIV module provides law enforcement officers with fast and flexible access to the data they need from multiple sources.

emergency management

The PIV solution can be used to authenticate First Responders within a restricted site and limit access to others, so that site control can be improved. The solution can also be used by EMT personnel to identify, record and treat those people affected by a disaster.

military

Mobile computer users in the military can leverage the PIV module to log in to government systems with their electronic smart card (Common Access Card) or contactless smart card, as required by the Department of Defense. They can also use the solution to positively identify and/or authenticate individuals in critical situations. In addition, the PIV module can be used to identify and track military personnel deployed around the world, from the beginning of their travels, through multiple stops, to their destination.
